Improved Efficiency Cellular Culturing Medium Filler with Pneumatic Receiving Platform

Improved Efficiency Cellular Culturing Medium Filler with Pneumatic Receiving Platform

Product Details:

Place of Origin: Qidong, Jiangsu
Brand Name: PERWIN
Certification: CE, ISO, GMP, UL, TUV, SGS
Model Number: PW-ZWGX550

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: Negotiable
Packaging Details: Export Standard Wooden Cases
Delivery Time: 60 working days
Payment Terms: TT
Supply Ability: 10pcs/month
Get Best Price Contact Now

Detail Information

Warranty: 1 Year Material: SUS304, SUS316L
Power Supply: 208V/60Hz Whole Line Power: About 10KW (subject To Actual Design)
Application: Filling Cell Culture Media And Animal Sera Pneumatic Components: SMC, Festo
Single Side Square Bottle Labeling Machine: Label Margin Detection And Alarm Function Including Pneumatic Receiving Platform Capping Method: 5 Sets Of Capping Units, Each Set Of Servo Motors Are Individually Controlled, Clockwise Capping And Anti-clockwise Capping

Product Description

Product Description:

The Cellular Culture Media Filling Machine is a high-performance automated system designed to fill and cap cellular culture media. It is equipped with a weighing unit, consisting of Mettler Load Cell and Controller, a marble floor installation foundation, and a 208V/60Hz power supply. The Weighing Module Controls The Liquid Level Change Of The Buffer Tank, and the host PLC controls the filling and capping process. The servo motor controls the positioning screw of the bottle separating and the bottle mouth positioning mechanism. It is composed of 5 sets of servo capping groups, and the servo motor controls the capping unit lifting type capping, with the lifting parameters of different specifications stored in the system. It also includes 5 heads servo-controlled peristaltic pump filling unit, with the servo motor controlling the filling needle lifting type filling, and the lifting parameters of different specifications stored in the system. The machine is equipped with an automatic protection function for filling needle deviation from the bottle mouth, anti-drip liquid receiving groove and anti-accumulation mechanism at the end of the bottle discharge screw. It also includes a 316L liquid distributor with 5 channels, and two sets of servo systems respectively control the filling and cap lifting mechanism. It is covered by a 304 stainless steel safety isolation cover, with tempered glass plate. The main low voltage electrical components are from Schneider.



Features:

  • Product Name: Cell Culture Media Filling Machine
  • Pneumatic components: SMC, Festo
  • Automatic sleeve labeling machine and heat shrinking machine: Contains About 5 Meters Of Conveyor Belt
  • Torque control method: Servo Technology
  • Filling solution: Liquid Which Is Easily Foaming
  • Cell culture medium filling machine, Cell culture media filler, Cellular culture medium filling machine


Technical Parameters:

Parameter Description
Zebra thermal transfer printer Bracket And Label Buffer Mechanism
Single side (or double side) labeling machine Mechanical Synchronization Of Top Pressure Positioning Mechanism, Horizontal Positioning Mechanism And Conveyor Belt, Three-in-one Power, Accurate And Stable Positioning
Warranty 1 Year
Power supply 220V 50Hz: Filling And Capping Machine And Sleeve Labeling Machine; 380V 50Hz: Heat Shrinking Machine, Labeling Machine
Filling program control Each Group Of Pumps Is Individually Controlled
Filling head lift Servo Motor Control
Servo system Bus Control
Photoelectric sensors OMRON, LION
Weighing module and related accessories 5 Sets Of Independent Mettler Load Cells And Controllers. Weighing Installation Unit. Replace Siemens PLC Model 600mm Conveyor Belt And 5 Sets Of Pneumatic Rejecting And Pushing Mechanism, Rejected Product Collection Platform, And Full Bottle Sensor
Filling method 5 Sets Of OEM Peristaltic Pumps, Watson-Marlow 505L Pump Heads, Driven By Servo Motors. Set And Adjust The Filling Volume On The Touch Screen
Cellular culture medium filler Cell culture media filler, Cellular culturing media filler


Applications:

PERWIN PW-ZWGX550 Cell Culture Media Filler

The PERWIN PW-ZWGX550 Cell Culture Media Filler is a powerful and efficient machine that is designed to fill media into bottles. It is certified by CE, ISO, GMP, UL, TUV, and SGS and has a minimum order quantity of 1. The price is negotiable and it is shipped in export standard wooden cases. It takes 60 working days for delivery and payment is accepted through TT. The supply ability is 10pcs/month.

The machine features a bottle-loading power transmission mechanism and bottle-separating automatic control system. It also has a storage bottle buffer for two packages (such as 500ml) unpacking table. The material used is SUS304 and SUS316L. It is equipped with a Watson-Marlow 505L Pump Head, driven by a servo motor, and has a filling accuracy of ≤±1%. The laminar flow hood is made of all stainless steel 304*1.0t material with a brushed surface treatment. The overall surface of the equipment has no burrs, no scratches, no oil stains and no defects that affect the appearance. It is in line with the new GMP specification and is equipped with an EBM centrifugal fan, a flow equalization membrane, adjustable wind speed, LED lighting, an independent control panel, a primary filter, an H14 high-efficiency filter, a high-efficiency resistance differential pressure gauge, and a PAO detection port. The stainless steel controller panel has liquid crystal display, is connected with the laminar flow wall plate plane, and has no steps and no bacteria dust collection. It also has multi-level adjustment of wind speed. The cleanliness is Class A and the power supply is 220V, 50Hz.

PERWIN PW-ZWGX550 Cell Culture Media Filler is the perfect machine for filling cell culture media into bottles. It has a high accuracy and is certified with various safety standards. Its advanced technology ensures that the filling process is fast and efficient.



Customization:

PERWIN PW-ZWGX550 Cellular Culture Media Filler is designed for accuracy and efficiency. It is certified with CE, ISO, GMP, UL, TUV, SGS and is of minimum order quantity 1. It is aseptic filling with ISO 5 HEPA and has a weight of 1500kg. The single side square bottle labeling machine features label margin detection and alarm function including pneumatic receiving platform. The automatic sleeve labeling machine and heat shrinking machine contains about 5 meters of conveyor belt. The main low voltage electrical is Schneider.

The PERWIN PW-ZWGX550 Cellular Culture Media Filler is designed to meet the needs of culture medium filling. It is an efficient and reliable automatic culture media filler machine. It has a competitive price and is backed by fast delivery of 60 working days. The supply ability is 10pcs/month and payment terms are TT. The export standard wooden cases ensure safe shipping.



Support and Services:

Our Media Filling Machine comes with a comprehensive technical support and service package. Our team of experienced engineers is available to provide assistance in operating the machine and answer any technical questions you may have. We also offer on-site installation and repair services as needed. We strive to provide the best customer service experience possible and look forward to serving you.



FAQ:

Q: What is the brand name of the Media Filling Machine?
A: The brand name of the Media Filling Machine is PERWIN.

Q: What is the model number of the machine?
A: The model number of the Media Filling Machine is PW-ZWGX550.

Q: Where is the machine manufactured?
A: The Media Filling Machine is manufactured in Qidong, Jiangsu.

Q: What certifications does the machine have?
A: The Media Filling Machine has CE, ISO, GMP, UL, TUV, and SGS certifications.

Q: What is the minimum order quantity for the machine?
A: The minimum order quantity for the Media Filling Machine is 1.
